Paint Starry Night into 1080p Colorful World
World’s FIRST & ANNKE-ONLY
Acme Color Night Vision
NightChormaTM NCA200 takes smart security to the next level with unrivaled acme color night vision. Say goodbye to boring B&W or blurry color night vision captured by traditional cameras. Instead, you can paint dark night into 1080p colorful world even in 0.001 lux conditions without ambient lighting, or 0 lux with the supplement light.
1080p Full HD at Smooth 30 fps
The 2MP CMOS image sensor is capable of recording (a DVR is needed) at a real-time 25/30 fps in 1080p Full HD. This high frame rate will help capture the precise & vivid moments in your gardens, garages, studios, luxury or jewelry stores, candy houses.
4 Top-of-the-Line Image Enhancement Technologies
The wired camera adopts 4 incredible image enhancement technologies – 130 dB WDR, 3D DNR, BLC & HLC – to provide the splendid 5MP Super HD clarity. So, whether you view the live stream by day or by moonlight, you’ll get a new level of details and colors that wasn’t possible before.
Industry-Leading H.265+ Video Format
24/7 Security with ANNKE 4K Ultra HD DVR
ANNKE 5MP DVR is the perfect cornerstone for your home & business security camera system. Pairing the NCA200 wired camera with this DVR, you can get remote live stream & playback, smart motion alerts and 24/7 recording (an HDD is needed) without monthly cloud storage fees.
Note: NCA200 needs a DVR for live stream & recording, and it CANNOT work standalone.
Built to Brave Extreme Hot & Cold Climates
Rated as IP66, this weatherproof camera can withstand pretty much anything, regardless of heavy snowfall, torrential downpours. This camera has been tested in extreme temperatures (-40 °F to 140 °F), ensuring all-year-round protection wherever you live.
Made from the same heavy-duty aluminum used in the construction of airplanes, the camera housing can withstand large impacts and is highly resistant to corrosion.
Metal
Rugged Housing
140 °F | 60 °C
Hot Rating
-40 °F | -40 °C
Cold Rating
IP66
Water Rating
What's in the Box
NCA200 Security Camera(s)5MP 8 Channel DVR (DW61LDBNC Cables(s)Mounting Screw Bag(S)(The quantity varies based on your choice.)User Manual
Camera
| Image Sensor2MP CMOS Image Sensor | Video Resolution1920 (H) X 1080 (V) |
| Lens2.8 mm | Angle of View121° |
| Min. Illumination0.001 Lux@(F1.0, AGC On), 0 Lux with White Light | Signal SystemTVI: 1080p@25 fps, 1080p@30 fps CVI: 1080p@25 fps, 1080p@30 fps AHD: 1080p@25 fps, 1080p@30 fps CVBS: PAL/NTSC |
| Number of Warm Light1 | Light DistanceUp to 65 ft/20 m |
| DNR3D DNR | Wide Dynamic Range130 dB WDR |
| Video OutputHD BNC X1 |
| Image Sensor1080p CMOS Image Sensor |
| Lens2.6 mm |
| Min. Illumination0.001 Lux@(F1.0, AGC On), 0 Lux with White Light |
| Number of Warm Light1 |
| DNR3D DNR |
| Video OutputHD BNC X1 |
| Video Resolution 1980 (H) X 1080 (V) |
| Angle of View 121° |
| Signal SystemTVI: 1080p@25 fps, 1080p@30 fps CVI: 1080p@25 fps, 1080p@30 fps AHD: 1080p@25 fps, 1080p@30 fps CVBS: PAL/NTSC |
| Light Distance Up to 65 ft/30 m |
| Wide Dynamic Range 130 dB WDR |
General
| HousingMetal | ColourWhite |
| Operating PowerDC 12 V | Indoor/OutdoorIndoor/Outdoor |
| Operating Temperature-40 °F – 140 °F/-40 °C – 60 °C | Dimension162.7 mm X 70 mm X 70.2 mm (6.41" X 2.75" X 2.75") |
| Weatherproof RatingIP66 | Weight0.57 lb./ 265.5 g |
| HousingMetal |
| Operating PowerDC 12 V |
| Operating Temperature-40 °F – 140 °F/-40 °C – 60 °C |
| Weatherproof RatingIP66 |
| Colour White |
| Indoor/Outdoor Indoor/Outdoor |
| Dimension162.7 mm X 70 mm X 70.2 mm (6.41" X 2.75" X 2.75") |
| Weight 0.57 lb./ 265 g |
Video & Audio
| Video CompressionH.264+/H.264/H.265/H.265+ | Video OutputHDMI and VGA Up to 1080P |
| 16CH Analog HD/Analog+2CH IP | Analog HD Recording ResolutionFor 5 MP stream access: 5MP Lite/3MP/1080p/720p/VGA/WD1/4CIF/CIF@12fps For 1080p stream access: 1080p/720p@12fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) |
| Audio Input/Output1/1 RCA | Analog HD Playback Resolution5MP Lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF |
| IPC Recording ResolutionUp to 6MP | IPC Playback ResolutionUp to 6MP |
| 16CH/ 16CH | ProtocolsSupport |
| Video CompressionH.264+/H.264/H.265/H.265+ |
| Video Input16CH Analog HD/Analog+2CH IP |
| Audio Input/Output1/1 RCA |
| IPC Recording ResolutionUp to 6MP |
| 16CH/ 16CH |
| Video Output HDMI and VGA Up to 1080P |
| Analog HD Recording Resolution For 5 MP stream access: 5MP Lite/3MP/1080p/720p/VGA/WD1/4CIF/CIF@12fps For 1080p stream access: 1080p/720p@12fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) |
| Analog HD Playback Resolution 5MP Lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF |
| IPC Playback Resolution Up to 6MP |
| Protocols Support |
Hard Drive
| HDD1 SATA interface | HDD CapacityUp to 6TB capacity |
| HDD1 SATA interface |
| HDD Capacity Up to 6TB capacity |
General
| Network interfaceRJ45x1(10/100M) | Working Condition-14 °F – 131 °F /-10 °C – 55 °C |
| BNC Output－ | Alarm Input/Output－ |
| RS485－ | USBUSB2.0x2 |
| Operating PowerDC12V | Dimensions(W x H x D)260 × 222 × 45 mm |
| Weight (without hard disk)≤ 1 kg (2.2 lb)(without HDD) |
| Network interfaceRJ45x1(10/100M) |
| BNC Output－ |
| RS485－ |
| Operating PowerDC12V |
| Weight (without hard disk)≤ 1 kg (2.2 lb)(without HDD) |
| Working Condition -14 °F – 131 °F /-10 °C – 55 °C |
| Alarm Input/Output － |
| USB USB2.0x2 |
| Dimensions(W x H x D) 260 × 222 × 45 mm |
